PG100 Intelligent Digital Pressure Gauge


หมวดหมู่ : MAC Sensor Pressure Gauge


PG100 Digital pressure gauge is full electronic-structure and  battery-powered, which make it very easy for on-site installation.Specifically, a high-precision piezo-resistive pressure sensor is used and the output signal is processed by the high-precision, low temperature drifting amplifier, then sent into the high-precision A/D converter to be converted into digital signal, after being computed and processed, the actual pressure value is showed on the LCD screen.

        It has benefits: flexible use, simple operation, easy debugging, safe, reliable etc. It is being widely used to measure and display the pressure of the medium in  hydro-power, water, petroleum, chemical, mechanical, hydraulic and other industries.

◆ Size 100mm,stainless steel case,

◆ Large-screen LCD display, high resolution,back light,easy to read

◆ five pressure display in real time

◆ Automatically record the maximum pressure values during the measurement

◆ Pressure on the percentage of dynamic display, (the progress bar display)

◆ 10 engineering units: psi, bar, kpa, Mpa, Kgf(kgf / cm2) , MMH(mmH2O),MH2(mH2O),

◆ 0 ~ 15min auto-shut off feature.

◆ Micro-power consumption, over 2 years in power-saving mode, continuous work 2,000 hours

◆ Parameter correction, correct zero and error in field application.

◆ Pressure range already setted before use

◆ Sampling rate: 4 times / sec

◆ Applicable to gases and liquids compatible with stainless steel

Datasheet PG100 Pressure Gauge MAC Sensor
