PG100 Digital pressure gauge is full electronic-structure and battery-powered, which make it very easy for on-site installation.Specifically, a high-precision piezo-resistive pressure sensor is used and the output signal is processed by the high-precision, low temperature drifting amplifier, then sent into the high-precision A/D converter to be converted into digital signal, after being computed and processed, the actual pressure value is showed on the LCD screen.
It has benefits: flexible use, simple operation, easy debugging, safe, reliable etc. It is being widely used to measure and display the pressure of the medium in hydro-power, water, petroleum, chemical, mechanical, hydraulic and other industries.
◆ Size 100mm,stainless steel case,
◆ Large-screen LCD display, high resolution,back light,easy to read
◆ Automatically record the maximum pressure values during the measurement
◆ Pressure on the percentage of dynamic display, (the progress bar display)
◆ 10 engineering units: psi, bar, kpa, Mpa, Kgf(kgf / cm2) , MMH(mmH2O),MH2(mH2O),
◆ 0 ~ 15min auto-shut off feature.
◆ Micro-power consumption, over 2 years in power-saving mode, continuous work 2,000 hours
◆ Parameter correction, correct zero and error in field application.
◆ Pressure range already setted before use
◆ Sampling rate: 4 times / sec
◆ Applicable to gases and liquids compatible with stainless steel
Datasheet PG80 Pressure Gauge MAC Sensor
