LC12 Series Smart Capacitance Level Sensors

LC12 Capacitance fuel level sensors operate on the basic principle of the linear variation of the electrical capacity formed between the inner and outer shell with the content shifty, transformed variation of the content level to 4~20mA, 0~5V, RS232, RS485 etc., could display liquid level height directly or be sent to the remote monitoring and control system by satellite.

Accuracy: ≤±1.0%F.S.

good stability and reliability

Precise linear and temperature compensation

Support local ZERO and SPAN calibration

Adjustable damp output time

Probe cut off available

Strong shock resistance

Pressure Range: 0-200 mm...1000mm optional

Probe Diameter: Φ12 mm (standard)

Accuracy: ≤ ±1.0%F.S (Typical);≤ ±0.5%F.S By Customized

(Linearity; Hysteresis; Repeatability)

Medium working Temp: -30 degree C to 85 degree C

Ambient Temp Span: -20 degree C to +65 degree C

Materials of probe: Aluminum Alloy

Output: 0-10V/4-20mA, RS232/RS485/0-5V/0.5-4.5V/ CANBUS, RS232/RS485

Power Supply: 15-28VDC, 9-28VDC, 5 V dc

Process connect port: M18*1.5 ,DN75 flange… (by customized)

Electronic connection: Fixed cable by stainless steel cap and Explore Proof and water proof IP67

Medium compatible: Diesel, gasoline and others fuel.

Datasheet LC12
