L705 Sewage Pressure Level Transducers & Transmitters

Share

Share

L705 is a fully sealed submersible level transducer/transmitter with thread and flange connector. It is made by building in high stable and reliable OEM piezo-resistive silicon pressure sensor and high accurate circuit board into the stainless steel housing. Integrated construction and standard signal provide the user easy and convenient application in the local working place. The special cable connects with housing, can be immerged into the media for a long time.

Anti-Blogging Filter cover design
Advanced digital temperature compensation.
Excellent resistance against impact, overload,
Shock and erosion.
Highly-efficient lighting absorption
and strong RFI & EMI resistance
1.5 times range standard overload.
3 times range burst pressure

Pressure Range: 0~1 M……200 M H2O optional
Output :4~20mA,0~5V/0.5~4.5V/0-10V
Power supply:+12VDC~+36VDC
Pressure port: Φ40 mm Thread with filter cover IP68
Accuracy :0.15%F.S,0.25%F.S, 0.5%F.S optional
Working temperature:-30℃~+100℃
Certificate:CE,RoSH
Application:City water,Drainage, Sewage pump station etc

Datasheet L705 Level Transmitter MAC Sensor
