L703 Submersible water Level transducer for water treatment



L703 is full sealed submersible level transducer/transmitter. It is made by building in high stable and reliable OEM piezo-resistive pressure sensor and high accurate circuit board into the stainless steel housing. Integrated construction and standard signal provide the user easy and convenient application in the local working place. The special cable connects with housing, can be immerged into the media for a long time.

For high temperature level application (up to 100 degree C), which is customized transmitters and manufacture with Germany sputtered film chips sensor, so the stability and quality very good.
L703 level transducer/transmitter has compact size, light weight and good stability; it can be used for water or liquid measure and control of medicine, metallurgy, electricity, mine, city water supply and drainage and hydrology, etc.

IP8 protection grade, waterproof and dustproof

316 L sensing diaphragm, All welded stainless steel housing

Waterproof and anti-blogging unique design process

Impact resistance and disturbance

1.5 times range standard overload.

3 times range burst pressure

Automatic design of temperature compensation

It Can be customized high temperature liquid level application

Universal Submersible Liquid Level Transducers

Pressure range: -1~1bar……1000 bar options

Output :4~20mA,0~5V/0~10V ,Hart protocol

Level Range: 0~0.5 M……500 M H2O optional

Output :4~20mA,0~5V/0.5~4.5V;RS485 ,RS232,Hart

Power supply:+12VDC~+36VDC

Accuracy :0.15%F.S,0.25%F.S, 0.5%F.S optional

Working temperature:-30℃~+85℃

Cable: PE cable with vents

Certificate: CE,RoSH

Application:Liquid measuring in tanks ,rivers ,lake,Sea,Well,Tube,underground water

Datasheet L703 Water Level Transmitter MAC Sensor
