PG60 Intelligent Digital Pressure Gauge is electronic-structure and battery-powered, which make it very easy for on-site installation. Specifically, a high-precision piezo-resistive pressure sensor is used and the output signal is processed by the high-precision, low temperature drifting amplifier, then sent into the high-precision A/D converter to be converted into digital signal, after being computed and processed, the actual pressure value is showed on the LCD screen.
◆ Large-screen LCD display, back light,high resolution,easy to read
◆ Automatically record the maximum pressure values during the measurement
◆ Pressure on the percentage of dynamic display, (the progress bar display)
◆ Five engineering units: psi, bar, kPa, MPa, kg / cm2
◆ 0 ~ 15min auto-off feature.
◆ Micro-power consumption, work over 2 years in power-saving mode,
2,000 hours continuous work.
◆ Parameter correction, correct zero and error in field application.
◆ Pressure range already set before use
◆ Sampling rate: 4 times / sec
◆ Applicable to gases and liquids compatible with stainless steel
