P403 Series Sanitary Flush Diaphragm Pressure Transmitters

คุณสมบัติสินค้า:

Share

P403 is sanitary flush diaphragm type pressure and level transmitters. It is made by building in high stable and reliable piezo-resistive silicon pressure sensor and high accurate circuit board into the stainless steel housing. Integrated construction and standard signal provide the user easy and convenient application in the local working place. The special cable connects with housing, can be immerged into the media for a long time. This model application in the field of water tank, Fuel tank, building& office water level measurement, city water supply, irrigation, food and sanitation, water factory, refinery, metallurgy, glass factory, swage dispose center, water supply, reservoir, river, sea…

Characters:

Accuracy: ≤±0.5%F.S.

Wide working temperature scope

Advanced digital temperature compensation.

Excellent resistance against impact, overload,

Shock and erosion.

Highly-efficient lighting absorption and strong RFI & EMI resistance

Impact resistance and disturbance

1.5 times range standard overload.

3 times range burst pressure

CE approving

Clamp Mounting Pressure Level Transmitter

Pressure range: -1~1bar……1000 bar options

Output :4~20mA,0~5V/0~10V ,Hart protocol

Pressure Range: -1 Bar-0-1 Bar.....600 Bar (for pressure measurement)

0-1 mH2O........500 mH2O Optional (for level measurement)

Output :4~20mA,0~5V/0~10V/0.5~4.5V,Digital RS485

Electronic connection: DIN 43650 Hirschman Terminal Box;

Fixed cable and water proof IP68 optional.

Power supply:+12VDC~36VDC

Pressure port: Clamp Φ50 mm

Accuracy :0.15%F.S,0.25%F.S, 0.5%F.S optional

Working temperature:-30℃~85℃(Non-Cooling Device); -30℃~150℃( With Cooling Device)

Certificate: Certificate: CE,RoSH

Medium compatible:Compatible with 316L Stainless Steel

EMC Standard:electromagnetic radiation:EN50081-1/-2

electromagnetic susceptibility:EN50082-2

Application:Food ,Juice,milk ,Sanitary liquid industry

Datasheet-P403 Flat Pressure Transmitter-MAC Sensor
