P10R OEM Compact Pressure Sensors



The P10 series pressure Sensors are applied in the refrigeration, compressor, engine fuel pressure, hydraulic pressure and gas pressure industries fields, which is adopt the Germany Ceramic piezoresistive technology and the advanced circuit design to avoid influences on the product caused by the temperature, humidity, mechanical fatigue and medium, thus to improve its permanent stability in the industrial environment. Its pressure chamber is made of ceramic and with high quality Japan CR or Teflon O-rings, free of leakage troubles. Digital circuits capable of strong RFI & EMI resistance and automatic temperature compensation are installed inside the transmitter and the transmitter is featured with the strong interference resistance, wide temperature compensation scope and flexible & various output forms, etc. The series products provide several optional pressure connectors and electric output forms for customers.

Sensitive sensing element, the precision of the output signal
Full sealed structure
P10 series with 7/16-20 UNF and thimble;
The scope of the standard temperature and pressure, and the application of air conditioning and refrigeration requirements

Pressure Range: -1-0-1 Bar.....600 Bar Optional

Pressure Type: Gauge pressure; Negative pressure; Absolute pressure optional

Accuracy: ≤ ±1.0%F.S (Standard), ≤ ±0.5%F.S (Customized)
(Linearity Hysteresis,Repeatability)
Medium Temp: -30℃~85℃

Temperature Compensation: 0℃~50℃

Housing material: 304 Stainless Steel

Output: 4~20mA, 0~5V/1~5V, 0~10 V, 0.5~4.5 V Ratiometric

Power Supply: 12~36 V DC, 8~36 V DC, 15~36Vdc, 5 V DC

Electronic connection: Terminal Box (DIN43650 Hirschman Connector, IP65);   Directly sealed cable IP67;

M12 4 Pins connector IP65;  Packard 3 Pins Connector IP67 are optional.

Pressure connect port: 1/8’’NPT male, 1/4’’NPT male 1/4’’NPT Female, G1/2’’ male, G1/4’’male/female,

7/16’’-20 UNF male/female are optional. (by Customized)

Certificate approving: CE Certificate.

Datasheet-P10 Pressure Sensor-MAC Sensor
